RK5 Class Fuse FRN-R-1 250V 1A-30A FRN-R-30 14X51MM Dual Element Time-delay fuses
Applications:
Provides motor overload, ground fault and
short-circuit protection
Helps protect motors against burnout from
overloads
Helps protect motors against burnout from
single-phasing on three-phase systems
Simplifies and improves blackout prevention(selective coordination)
Dual-element fuses can be applied in circuits subject to temporary motor overloads and surge
currents to provide both high performance short-circuit and overload protection
The overload element provides protectionagainst low level overcurrent of overloads
and will hold an overload which is five times
greater than the ampere rating of the fuse for a
minimum of ten seconds
RK5 Class Fuse advanced protection,energy efficient FRN-R Class RK5 dual element,current-limiting, time-delay fuses with optionalopen fuse indication on select ratings. Time-delay– 10 seconds (minimum) at 500% of rated current(8 seconds for 1⁄10-30A sizes)
FRN-R-1/10
FRN-R-1
FRN-R-2
FRN-R-3
FRN-R-4
FRN-R-5
FRN-R-6
FRN-R-6-1/4 6.25A
FRN-R-7
FRN-R-8
FRN-R-9
FRN-R-10
RK5 Fuse 250Vac 125Vdc 35A-60A 21X76MM Dual Element Time-delay fuses FRN-R-35 FRN-R-60
FRN-R-40
FRN-R-45
FRN-R-50
FRN-R-60
| General specifications | | |
| | Product Name | FRN-R fuse |
| | Catalog Number | FRN-R-35 |
| | Product Length/Depth | 3 in |
| | Product Height | 0.81 in |
| | Product Width | 0.81 in |
| | Product Weight | 1.95 lb |
| Electrical rating | | |
| | Amperage Rating | 35 A |
| | Interrupt rating | 20 kAIC at 125 Vdc 200 kAIC at 250 Vac |
| | Response time | 10 sec at 500% |
| | Voltage rating | 250 Vac, 125 Vdc |
| Physical details | | |
| | Number of elements | Dual |
| | Packaging type | Standard |
| General information | | |
| | Class | Class RK5 |
| | Connection | Ferrule end x ferrule end |
| | Fuse indicator | Non-indicating |
| | Special features | Finger safe |
